Armoring PureDarwin

This page describes some ways to hardening PureDarwin (and intrinsically Darwin 9).
Please feel free to contribute.

This is a draft, not clean and totally incomplete, also not really well sorted.
Take extreme caution if you decide to apply or test some part of this guide, it's a draft.

Preamble

"Know your enemy" - Rage Against the Machine

Dictionary
harden |ˈhärdn|
verb
make or become hard or harder : [ intrans. ] wait for the glue to harden | [ trans. ] bricks that seem to have been hardened by firing.
  • make or become more severe and less sympathetic : [ trans. ] she hardened her heart.
  • make or become tougher and more clearly defined : [ intrans. ] suspicion hardened into certainty.
  • [ intrans. ] (of prices of stocks, commodities, etc.) rise and remain steady at a higher level.

Disclaimer

 WARNING!  YOU HAVE BEEN WARNED! NOW HOPE YOU KNOW WHAT YOU DO!  WARNING!

See above, you have been warned in red.
Also, take a look at Legal page.


Before installation

Usage

Assuming PureDarwin will be installed on /Volume/Puredarwin, these two variables below could be used in the following information.

export VOLUME="/Volume/PureDarwin"
export DISK=`/bin/df | /usr/bin/grep "^/Volume/PureDarwin" | awk -F ' ' '{print $1}'`

You can also use setenv, according to your favorite shell.
Note that the ownership of the session is root.

Command-line tools to securely erase

diskutil

Securely erase a disk on $DISK

diskutil secureErase <level> $DISK

Securely erase freespace of a disk on $DISK

diskutil secureErase freespace <level> $DISK

3 levels are available in `man diskutil`:
  1. Single pass randomly erase the disk
  2. US DoD 7 pass secure erase
  3. Gutmann algorithm 35 pass secure erase

rm

`rm' with -P option will overwrite file(s) 3 times, first with the byte pattern 0xff, then 0x00 and finally 0xff before deleting them.

srm

Securely remove files or directories:

srm -r -m dir

Same as above, 3 levels available in `man srm':
-s  overwrites with a single pass of random data
-m is the 7 US DoD compliant passes (0xF6, 0x00, 0xFF, random, 0x00, 0xFF, random)
If neither is specified, the 35-pass Gutmann algorithm is used

Misc

Slim down pd_roots & pd_drivers list

Probability says pd_roots & pd_drivers may include unused packages with potential vulnerabilities.

By default, the list is big, too big:

cat pd_roots pd_drivers | wc -l
     183

Knowing what you're doing, you can safely remove more than hundred packages.

hdiutil compression

hdiutil uses the DiskImages framework (FileVault encryption is supported) to manipulate disk images.

If you want to compress a folder:

hdiutil create -srcfolder "<folder>" -format UDBZ <compressed folder>.dmg
srm -r <folder>

In order to mount it later, it can be attached using hdiutil:

mkdir <folder>
hdiutil attach -mountpoint <compressed folder>.dmg


System startup

Extensible Firmware Interface (EFI)

EFI determines which partition or disk to load. It also determines whether the user can enter (or not) in singe-user mode.
More information in efibootboot and the boot process pages.

Creating an EFI password disables:
  • the single-user mode
  • loading of unapproved partition or disk
  • target disk mode at startup

BIOS

"Cliché", assign a BIOS password in order to prevent potential way to access the OS by booting alternative media.

Fortify single-user mode

Altering rc.common (caution)

if [ "${BootType}" = "singleuser" ];then
    authentification.sh
fi

Assuming authentification.sh is a "nice" script.

Using the deprecated /etc/passwd

According to the file itself, in the first comments:

# Note that this file is consulted directly only when the system is running
# in single-user mode. At other times this information is provided by
# Open Directory.

Try to change the shell PATH from:

root:*:0:0:System Administrator:/var/root:/bin/sh

to:

root:*:0:0:System Administrator:/var/root:/dev/null

Remove single user mode support from XNU

If you remove/disable the code portion of what activate/detect the single user mode (-s), there is no way to enter in single user mode.
A patch is needed in this case (TODO)

Encrypt around

FIXME

Configuring Access Warnings

FIXME

PKI

PKI


System

Processus & memory

Keep in mind, that any binary you would like to run, can have already been compromised or can be compromised at run-time.
A possible approach is to use your own trusted binary from a read-only medium (when possible), taking in account how your binary is loaded and run in memory. As an illustrative example, `netstat' is well known to be easily short-circuited in order to not show some connections (and several ways exist..).

Oldschool UNIX utility

There are plenty "oldschool" UNIX utility, for historical causes, posterity purpose or simply because there are still usefull, as some of them:
  • kill, killall, netstat, ps, sysctl, top, uptime, w, who, ...
We can also find specific utility to Darwin, or at least to BSD subsystems also detailled below.

sysctl

Retrieving memory status is easy:
sysctl -a | grep mem
hw.physmem = 2147483648
hw.usermem = 1810808832
hw.memsize = 2147483648
hw.memsize: 2147483648

A more human readable result of the swap usage:
sysctl -a | grep swap
vm.swapusage: total = 1024.00M  used = 416.94M  free = 607.06M

hostinfo

Mach kernel version:
Darwin Kernel Version 9.1.0: Wed Oct 31 17:46:22 PDT 2007; root:xnu-1228.0.2~1/RELEASE_I386
Kernel configured for up to 2 processors.
2 processors are physically available.
2 processors are logically available.
Processor type: i486 (Intel 80486)Processors active: 0 1
Primary memory available: 1.00 gigabytes
Default processor set: 52 tasks, 211 threads, 2 processors
Load average: 0.02, Mach factor: 1.96

Mach virtual memory statistics: vm_stat

Rudimentary command, an (different) alternative of the missing `free' UNIX utility.

Mach Virtual Memory Statistics: (page size of 4096 bytes)
Pages free: 19385.
Pages active: 131831.
Pages inactive: 51339.
Pages wired down: 58216.
"Translation faults": 6266580.
Pages copy-on-write: 161179.
Pages zero filled: 3302531.
Pages reactivated: 5342.
Pageins: 167299.
Pageouts: 3430.
Object cache: 24703 hits of 77103 lookups (32% hit rate)

Some particular value needs to be watch, as the Pageouts number values. If it goes more than 0, it simply means that your memory is swapping which is not what you want, most of the time.
Swapping can result in potential sensitive information dumped from memory to the harddisk (in the swapfile(s)).
Swapping can also happen simply because not enough memory is available.

Moving swap file

FIXME

Manipulate power management settings with pmset

According to the man, pmset changes and reads power management settings such as idle sleep timing, wake on administrative access, automatic restart on power loss, etc.

Changes are saved in a persistent plist file at /Library/Preferences/SystemConfiguration/com.apple.PowerManagement.plist
Scheduled power on/off events are stored separately in /Library/Preferences/SystemConfiguration/com.apple.AutoWake.plist

From the man:

     boot - tell the kernel that system boot is complete (normally LoginWindow does this). May be useful to Darwin users.

FIXME

Disable computer sleep

pmset -a sleep 0

0 to set the idle time to never

Enable hard disk sleep (disk spindown timer)

pmset -a disksleep 1

Disable wake on ethernet magic packet

pmset -a womp 0

Disable automatic restart on power loss

pmset -a autorestart 0

Disable computer sleep when power button is pressed

pmset -a powerbutton 0

Permissions and filesystem

POSIX restrictive style

Use restrictive file mode as possible. Avoid file readable by anyone and writable (typically a 644) by the owner only.

chmod 600 *

Idem for folders.

sudo chmod 700 /Users/<username>

Change global umask file permission

Persistent effects. (FIXME NOT TESTED)

sudo defaults write /Library/Preferences/.GlobalPreferences NSUmask 77

You can also use non persistent umask command illustrated by the example just below.

aladin@niwarderup:~/test% touch before_umask
aladin@niwarderup:~/test% mkdir before_umask_dir
aladin@niwarderup:~/test% umask 77
aladin@niwarderup:~/test% touch after_umask
aladin@niwarderup:~/test% mkdir after_umask_dir
aladin@niwarderup:~/test% ls -l
total 0
-rw-r--r-- 1 aladin staff  0 Jun 20 19:07 before_umask
drwxr-xr-x 2 aladin staff 68 Jun 20 19:07 before_umask_dir
-rw------- 1 aladin staff  0 Jun 20 19:07 after_umask
drwx------ 2 aladin staff 68 Jun 20 19:07 after_umask_dir

Extended Attributes

Extended attributes extend the basic attributes associated with files and directories in the file system.
They are stored as name:data pairs associated with file system objects (files, directories, symlinks, etc).
xattr

ls -@l <file>
FIXME

Locking file with chflags

Set the user immutable flag (owner or super-user only):

chflags uchg filename.txt

Unlocking file with chflags

Clear the user immutable flag (owner or super-user only):

chflags nouchg filename.txt

The suid/sgid (set-user/group-ID-on-execution) bit

Executable files with this bit set will run with effective uid set to the uid of the file owner. Moreover, directories with the set-user-id bit set will force all files and sub-directories created in them to be owned by the directory owner and not by the uid of the creating process.

find / -type f -perm -04001 -ls > suid-files
find / -type f -perm -02001 -ls > sgid-files
find / -type f -perm -04001 -user 0 -ls > suid-root
find / -type f -perm -02001 -group 0 -ls > sgid-root
find / -type f -perm -02001 -group 80 -ls > sgid-admin

This is a simple and effective example on Mac OS X (9.4.0) showing how suid is dangerous:

whoami
aladin

id
uid=501(aladin) gid=20(staff) groups=20(staff),98(_lpadmin),80(admin)

osascript -e "tell app \"ARDAgent\" to do shell script \"whoami\""
root

osascript -e "tell app \"ARDAgent\" to do shell script \"id\""
uid=0(root) gid=0(wheel) egid=20(staff) groups=0(wheel),1(daemon),2(kmem),8(procview),29(certusers),3(sys),9(procmod),4(tty),5(operator),80(admin),20(staff)

Find writable file(s)

find / -type f -perm -02 -ls

Find writable dir(s)

find / -type d -perm -02 -ls

Kext permission rules

  • All files and folders in the KEXT, including the KEXT itself, must be owned by the root user (uid 0)
  • All files and folders in the KEXT, including the KEXT itself, must be owned by the wheel group (gid 0)
  • All folders in the KEXT, including the KEXT itself, must have the permissions 0755 (octal)
  • All files in the KEXT must have permissions 0644 (octal)
  • A KEXT is not the place to store a user-space executable.
/usr/sbin/chown -R root:wheel MyKEXT.kext

find MyKEXT.kext -type d -exec /bin/chmod 0755 {} \;
find MyKEXT.kext -type f -exec /bin/chmod 0644 {} \;

Hard link

fixme

Symbolic link

fixme

diskutil

Verify and repair permission

When you use diskutil to verify or repair disk permissions, it reads the Bill of Materials files from the Darwin installation and compares its list to the permissions on each file listed.

If the permissions differ, diskutil can repair them.

diskutil repairPermissions $PUREDARWIN

Enable journaling (if supported by the FS)

diskutil enableJournal $PUREDARWIN/

Encrypting data

System swap

The kernel uses a pool of external swap files to support demand paging.
Caution, it seems swap files aren't erased securely at startup.
Swap files reside in /private/var/vm/ directory:

-rw------T  1 root  wheel    67108864 Jun 22 11:51 swapfile0
-rw------T  1 root  wheel    67108864 Jun 22 19:02 swapfile1

An external storage manager for dynamic pager is running as root, showing by `ps aux | grep dynamic`

root        26   0.0  0.1    75376    704   ??  Ss   11:50AM   0:00.01 /sbin/dynamic_pager -F /private/var/vm/swapfile

Launched with /System/Library/LaunchDaemons/com.apple.dynamic_pager.plist

Disable swap file (caution)

Disabling swap needs caution.

Some program may require explicitly swap memory area.
What happens if no more physical memory available and swap is disabled?

Non persistent way:

sudo killall dynamic_pager
sudo srm /private/var/vm/swapfile*

Persistent way:
Edit /System/Library/LaunchDaemons/com.apple.dynamic_pager.plist and remove the nodes:

<string>/sbin/dynamic_pager</string>
<string>-F</string>
<string>/private/var/vm/swapfile</string>

Alternatively, the Disabled <boolean> optional key is used to disable (or not) the job.

Then wipe free space.

Encrypted swap file

This is essentially used to prevent some potential local user "deviance".
PureDarwin, if it is not yet the case, will provide by default an encrypted swap partition.

The `dynamic_pager' daemon have an option to enable encryption:

     -E      Encrypt the data in the swap files.

Not sure if it is still working but.. try to put ENCRYPTSWAP=-YES- in /etc/hostconfig or add the the respective launchd plist the corresponding arg.

Notes: Notice another mysterious option:
     -P      This option is currently unimplemented.
Although in the short getopt:
dynamic_pager: illegal option -- h
usage: dynamic_pager [-F filename] [-L low water alert trigger] [-H high water alert trigger] [-S file size] [-P priority]

Encrypt (and password protect) a folder with hdiutil


hdiutil create -encryption AES-256 -stdinpass -srcfolder <folder> <encrypted folder>.dmg


Decrypt a folder with hdiutil


hdiutil attach -stdinpass <encrypted folder>.dmg


FileVault

256-bit and 128-bit AES keys support.

Bad, filevault key are protected by user/password.
FIXME

gpg

FIXME

Users & accounts

Creating user account

Some scripts as `pd_adduser' or `pd_injectuser', or the more regular `dscl' and `passwd' binaries can be used in order to create and manage user accounts. See Download page and User management page.

Reset a user's password in single user mode

Boot into single user mode. Replace username with the targeted user and password with the desired password, then:

fsck -fy
mount -uw /
launchctl load /System/Library/LaunchDaemons/com.apple.DirectoryServices.plist
dscl . -passwd /Users/username [password]

Then reboot, or relaunch DirectoryServices.

Note that you can also use pd_injectuser to recreate a user account, including his password.

/usr/local/sbin/pd_injectuser

Disable root account

dsenableroot -d -u username -p userpassword

Enable root account (caution)

dsenableroot -u username -p userpassword -r rootpassword

Restrict sudo use

Edit /etc/sudoers and limit the use of sudo to a single command per auth by adding:

Defaults timestamp_timeout=0

Edit /etc/sudoers in order to restrict who can run sudo by removing:

%admin ALL=(ALL) ALL

and add for each <user>:

<user>  ALL=(ALL) ALL

ACL

Enable file ACL on the root file system

sudo fsaclctl –p / -e

Disable file ACL on the root file system

sudo fsaclctl –p / -d

Enable user based ACL for a file

Read access:

chmod +a "<user> allow read" <file>

Enable group based ACL for a file

Allow write access:

chmod +a "<group> allow write" <file>

Deny write access specifically:

chmod +a "<user> deny write" <file>

View ACLs

ls -le <file>

sandbox: a role-based access control system

FIXME
A kernel-enforced access control, applied at the system call of XNU.
Flexible policies?

Compiled from Scheme (LISP inside ;)) programs/rules in /usr/share/sandbox.
Rules support from SYSV IPC to BSD sysctl via signals.
FIXME

Logging

Cron audit

Look /etc/periodic/*
FIXME

syslogd

Edit /etc/syslog.conf.

To log authentication error messages (also the remote ones) in /var/log/secure.log, change the line

authpriv.*;remoteauth.crit /var/log/secure.log

to

authpriv.*;remoteauth.err;auth.err /var/log/secure.log

Limit number of message a syslogd rule generate

Enable facility of LOG_SECURITY:

/usr/sbin/sysctl -w net.inet.ip.fw.verbose=1

Add logamount <number> after the log keyword
Setting <number> to 0 removes limit.

local system logging

FIXME
/etc/newsyslog.conf configuration can sets
  • log file rotation based on size, last rotation time, or time of day
  • secure permissions to log files at rotation time

remote system logging

Local logging is not really reliable if the computer is compromised, local files can be modified, removed or short-circuited

Open /etc/syslog.conf to enable remote logging.
Add to the top:

*.* @<remote log server address or host>

Restart `syslogd' with a hangup signal (or via launchctl):

sudo killall –HUP syslogd

Edit /etc/syslog.conf and add /var/log/secure.log and /var/system.log to the host <host>:

authpriv.*;remoteauth.err;auth.err @<host>
*.notice;authpriv,remoteauth,ftp,install.none;kern.debug;mail.crit @<host>

FIXME

Process accounting

FIXME
Logs all commands executed by all users.

To enable process accounting, create /var/account folder.

sudo mkdir -p /var/account

Create /var/account/acct to store process accounting information:

sudo touch /var/account/acct
chown -R root:admin /var/account
chmod -R 660 /var/account

Start accounting on the system:

sudo accton /var/account /acct

It is launched at boot.

Use `lastcomm`to get information on previously executed commands.

Enable security audit

FIXME
Open /etc/hostconfig and add:

AUDIT=-YES-

Restart.

audit -n rotates the current log file.
audit -s rotates the current log file and forces to reload settings from the audit_control file

last, wtmp & utmp

The file /var/run/utmp stores information about the currently logged-in user, whereas /var/log/wtmp tracks all user logins/logouts, shutdowns, reboots, and crashes.
Deprecated but sometimes usefull.

Log files (non exhaustive list)

FIXME
/var/log/cups
/var/log/ftp.log
/var/log/httpd
/var/log/lastlog
/var/log/wtmp
/var/log/lookupd.log
/var/log/lpr.log
/var/log/secure.log
/var/log/system.log
/var/log/ipfw.log
/var/log/fsck_hfs.log

/var/run/utmp

Library/Logs/

Debugging

Some tools

FIXME

leak

FIXME
Leaked memory identification and other unreferenced malloc buffers.

heap

FIXME
List all the malloc-allocated buffers in the process's heap.

malloc_history

FIXME
malloc_history inspects a given process and lists the malloc allocations performed by it.

vmmap

FIXME

Disable Core Dumps

FIXME
To prevent the kernel from creating core dumps:

kern.coredump=0 in /etc/sysctl.conf

The non persistent way:

sysctl -w kern.coredump=0

Limit core dump

Enable core dumps by adding the line limit core unlimited in /etc/launchd.conf (persistent way).

The resulted dump(s) will be stored in /cores folder:
file /cores/core.57
/cores/core.57: Mach-O core i386

Or from a shell (non persistent): ulimit -c unlimited

Notes: kill -ABRT <pid> could be used in order to generate a core dump.
On Darwin8, change the line "COREDUMPS=-NO-" in /etc/hostconfig to "COREDUMPS=-YES-"

launchd

FIXME
To send all launchd logs to a file, add in /etc/syslog.conf:

launchd.* /var/log/launchd.log

Restart syslogd:

sudo kill -HUP `cat /var/run/syslog.pid`

To increase the level of debugging:

sudo launchctl log level debug Password: ********

FIXME
See launchd page.

Enable lookupd debugging

sudo dscl . create /dsRecTypeStandard:Config/lookupd Debug YES
sudo dscl . create /dsRecTypeStandard:Config/lookupd Trace YES

Edit /etc/syslog.conf and replace netinfo.err by netinfo.debug

Restart daemons

sudo kill -HUP `cat /var/run/syslog.pid`
sudo kill -HUP `cat /var/run/lookupd.pid`

Disable lookupd debugging

sudo dscl . delete /dsRecTypeStandard:Config/lookupd

Edit /etc/syslog.conf and replace netinfo.debug with netinfo.err

Restart daemons

sudo kill -HUP `cat /var/run/syslog.pid`
sudo kill -HUP `cat /var/run/lookupd.pid

diskarbitrationd

FIXME
Open /System/Library/LaunchDaemons/com.apple.diskarbitrationd.plist:

    <key>ProgramArguments</key>
    <array>
        <string>/usr/sbin/diskarbitrationd</string>
    </array>

and simply append "-d":

    <key>ProgramArguments</key>
    <array>
        <string>/usr/sbin/diskarbitrationd -d</string>
    </array>
FIXME

fs_usage

fs_usage reports system calls and page faults related to filesystem activity in real-time, often usefull for debugging.
Remember by default (without any options), fs_usage itself, Terminal, telnetd, sshd, rlogind, tcsh, csh and sh processes are excluded from the output.

Identify files used by an application at launchtime:

sudo fs_usage -w | grep <application>

-w options forces wider, detailed, output.

FIXME

DTrace

The generic front-end to the DTrace facility is a powerfull dynamic debugger and analysis tool.
See the DTrace page.

Recompiling XNU

FIXME
See The XNU kernel page.

Usefull MacPorts

kernel-tools sysutils/kernel-tools 8J2135 Tools required to build xnu for Intel
gcc_select sysutils/gcc_select 0.1 Switch the default compiler

After kernel-tools installed, the compilation will fail irremediably with some tool not found in /usr/local/bin/.
A quick fix with symbolic links:

/usr/local/bin/check_dylib->/opt/local/bin/check_dylib
/usr/local/bin/checksyms->/opt/local/bin/checksyms
/usr/local/bin/cmpshlib->/opt/local/bin/cmpshlib
/usr/local/bin/decomment->/opt/local/bin/decomment
/usr/local/bin/hack_libgcc->/opt/local/bin/hack_libgcc
/usr/local/bin/indr->/opt/local/bin/indr
/usr/local/bin/kern_tool->/opt/local/bin/kern_tool
/usr/local/bin/kextsymboltool->/opt/local/bin/kextsymboltool
/usr/local/bin/mkshlib->/opt/local/bin/mkshlib
/usr/local/bin/seg_addr_table->/opt/local/bin/seg_addr_table
/usr/local/bin/seg_hack->/opt/local/bin/seg_hack
/usr/local/bin/relpath->/opt/local/bin/relpath

Configuration files involved

FIXME

bsd/conf/MASTER           iokit/conf/MASTER.i386    libsa/conf/MASTER         osfmk/conf/MASTER.i386    security/conf/MASTER
bsd/conf/MASTER.i386      libkern/conf/MASTER       libsa/conf/MASTER.i386    pexpert/conf/MASTER       security/conf/MASTER.i386
iokit/conf/MASTER         libkern/conf/MASTER.i386  osfmk/conf/MASTER         pexpert/conf/MASTER.i386

Note we don't use MASTER.ppc files although they are still existing.

Before

FIXME

ProductName: Mac OS X

ProductVersion: 10.5.4

BuildVersion: 9E17


gcc version:

Using built-in specs.
Target: i686-apple-darwin9
Configured with: /var/tmp/gcc/gcc-5465~16/src/configure --disable-checking -enable-werror --prefix=/usr --mandir=/share/man --enable-languages=c,objc,c++,obj-c++ --program-transform-name=/^[cg][^.-]*$/s/$/-4.0/ --with-gxx-include-dir=/include/c++/4.0.0 --with-slibdir=/usr/lib --build=i686-apple-darwin9 --with-arch=apple --with-tune=generic --host=i686-apple-darwin9 --target=i686-apple-darwin9
Thread model: posix
gcc version 4.0.1 (Apple Inc. build 5465)

Easy compilation

FIXME

make KERNEL_CONFIGS="RELEASE" all VERBOSE=YES
FIXME

After

FIXME

Tweaking XNU

Secure levels "à la OpenBSD"

This is not yet implemented nor investigated.
Some security concepts "à la OpenBSD" could be reused into Darwin, at least partially.

Security levels well known in OpenBSD “world” is going to be partially (and step by step) introduced and reused into PureDarwin. According to OpenBSD website, “Security levels essentially set how the kernel will handle system security”.


In OpenBSD, there are four security levels, from the less to the most secure level: -1, 0, 1, 2

In PureDarwin, nyi.

In OpenBSD, securelevels are set from /etc/rc.securelevel
In PureDarwin, nyi. securelevels are set from [unknown location/securelevel.plist]

In OpenBSD, the end of the boot process is showing which security level is used.
In PureDarwin, nyi.

In OpenBSD, sysctl kern.securelevel=x can be used to adjust "on live" the security level. In order to adjust from a higher security level to a lower security level, a reboot is needed.
In PureDarwin, `sysctl' is reporting the option (but not yet tested)
kern.securelevel = 0
kern.securelevel: 0
kern.secure_kernel: 0

In OpenBSD, securelevel -1: no additional kernel security features, nor restrictive permission. Not for production use.
In OpenBSD, securelevel 0: used at first boot. If securelevel 1 is set, it will be used after the boot process finish. There are no added features of securelevel 0.
In PureDarwin, ?

In OpenBSD, securelevel 1: /dev/mem and /dev/kmem cannot be write. Raw disk are read-only. etc...

In OpenBSD, securelevel 2: ...

Removing debug info

FIXME.
Take care of MACH_DEBUG.

According to osfmk/conf/MASTER configuration file:

# MACH_DEBUG enables the mach_debug_server, a message interface used to

# retrieve or control various statistics. This interface may expose data

# structures that would not normally be allowed outside the kernel, and

# MUST NOT be enabled on a released configuration.
options
MACH_DEBUG # #

options MACH_IPC_DEBUG # #

#

options MACH_VM_DEBUG # # <debug>

FIXME

authorization right

FIXME
/etc/authorization


Network

Disable IPv6

networksetup -setv6off $iface

ifconfig

Use a restrictive netmask.

Detecting promiscuous mode

Several ways exist to detect promiscuous mode (potential running sniffer), you can use DTrace, simply parse `ifconfig' or even run a sniffer.

Without promisc mode, ifconfig looks like

/sbin/ifconfig en0
en0: flags=8863<UP,BROADCAST,SMART,RUNNING,SIMPLEX,MULTICAST> mtu 1500
                ether 00:19:**:**:**:**
                media: autoselect status: inactive
                supported media: autoselect 10baseT/UTP <half-duplex> 10baseT/UTP <full-duplex> 10baseT/UTP <full-duplex,hw-loopback> 10baseT/UTP <full-duplex,flow-control> 100baseTX <half-duplex> 100baseTX <full-duplex> 100baseTX <full-duplex,hw-loopback> 100baseTX <full-duplex,flow-control> 1000baseT <full-duplex> 1000baseT <full-duplex,hw-loopback> 1000baseT <full-duplex,flow-control> none

With promisc mode activated:

/sbin/ifconfig en0
en0: flags=8963<UP,BROADCAST,SMART,RUNNING,PROMISC,SIMPLEX,MULTICAST> mtu 1500
        ether 00:19:**:**:**:**
        media: autoselect status: inactive
        supported media: autoselect 10baseT/UTP <half-duplex> 10baseT/UTP <full-duplex> 10baseT/UTP <full-duplex,hw-loopback> 10baseT/UTP <full-duplex,flow-control> 100baseTX <half-duplex> 100baseTX <full-duplex> 100baseTX <full-duplex,hw-loopback> 100baseTX <full-duplex,flow-control> 1000baseT <full-duplex> 1000baseT <full-duplex,hw-loopback> 1000baseT <full-duplex,flow-control> none

netstat

Be carefull with netstat, it is not so hard to compromise "its results".

netstat -anp tcp
netstat -anp udp

lsof

lsof -i tcp
lsof -i udp

Firewall

ipfw

The default rule is not really restrictive:
#ipfw list
65535 allow ip from any to any

Same for the IPv6 network stack, the default rules list looks like:
ip6fw list
33300 deny ipv6-icmp from any to any in icmptype 128
65535 allow ipv6 from any to any

ipfw traffic shapping

If the bandwidth used can be known (estimation at least; if the use is "constant" it is really efficient) in advance, allocating only the requested amount will not let enough "space" (bandwidth) available for an intruder.

As an example, create a pipe that only allows up to 42KB/s to go through.

sudo ipfw pipe 1 cgonfi bw 42KByte/s

Attach that pipe to the outgoing traffic on port 22, effectively limiting the outgoing traffic of sshd.

sudo ipfw add 1 pipe 1 src-port 22

Remove the pipe from the port.

sudo ipfw delete 1

firewall state in sysctl

The state of the firewall (enabled or disabled) can be changed by directly changing a kernel parameter.

Enable the firewall (default):
sysctl -w net.inet.ip.fw.enable=0

Disables the firewall:
sysctl -w net.inet.ip.fw.enable=1

More info:
net.inet.ip.fw.verbose_limit: 0
net.inet.ip.fw.verbose: 2
net.inet.ip.fw.debug: 0
net.inet.ip.fw.one_pass: 0
net.inet.ip.fw.autoinc_step: 100
net.inet.ip.fw.enable: 1

Rules examples

TODO

Block dns multicast (5353)

grep -i 5353 /etc/services
mdns            5353/udp    # Multicast DNS
mdns            5353/tcp    # Multicast DNS
FIXME

Activating NAT on server side

FIXME
Create /etc/natd.conf and add:

interface en0
same_ports yes
use_sockets yes
unregistered_only yes

Add dynamic yes if you have a dynamic IP.
Add log_denied no if you want to log packets blocked by the NAT device

Configure internal interface en0 with a private address (i.e: 192.168.1.1)

Enable IP forwarding in the kernel, it's needed.
Non persistent way:

sysctl -w net.inet.ip.forwarding=1

Persistent way, in /etc/hostconfig, add or change the value to IPFORWARDING=-YES-

Route packets from the internal network to the external one via en0:

ipfw add divert natd ip from any to any via en0

Launch natd:

/usr/sbin/natd -f /etc/natd.conf

Use NAT on client side

IP address: 192.168.1.* (obviously 192.168.1.1 is reserved)
Subnet mask: 255.255.254.0
Gateway/default router: 192.168.1.1
DNS servers: same as the router (but not necessarily)

Enable a caching name server on NAT server side

In /etc/hostconfig, add or change the line to DNSSERVER=-YES-

Services

Cups

FIXME
By default, all local user can access to http://127.0.0.1:631 (a web admin front-end).

Enable cupsd service

sudo launchctl load -w /System/Library/LaunchDaemons/org.cups.cupsd.plist

Disable cupsd service

sudo launchctl unload -w /System/Library/LaunchDaemons/org.cups.cupsd.plist
FIXME

ftp

Disable ftp

launctl unload -w /System/Library/LaunchDaemons/ftp.plist

Enable ftp

launctl load -w /System/Library/LaunchDaemons/ftp.plist

Samba

Disable SMB

defaults delete /Library/Preferences/SystemConfiguration/com.apple.smb.server EnabledServices
launctl unload -w /System/Library/LaunchDaemons/nmbd.plist
launctl unload -w /System/Library/LaunchDaemons/smbd.plist

AFP

Disable Apple File Server


launctl unload -w /System/Library/LaunchDaemons/com.apple.AppleFileServer.plist

ntp

FIXME
/etc/ntp.conf

NFS

FIXME

Disable NFS

launchctl unload -w /System/Library/LaunchDaemons/com.apple.portmap.plist
launchctl unload -w /System/Library/LaunchDaemons/org.postfix.master.plist

Enable NFS

launchctl load -w /System/Library/LaunchDaemons/com.apple.portmap.plist
launchctl load -w /System/Library/LaunchDaemons/org.postfix.master.plist

Bonjour


FIXME

Disable Bonjour

sudo launchctl load -w /System/Library/LaunchDaemons/com.apple.mDNSResponder.plist

Enable Bonjour

sudo launchctl load -w /System/Library/LaunchDaemons/com.apple.mDNSResponder.plist

Change Bonjour hostname

No spaces or non-DNS characters allowed for <hostname>

scutil --set LocalHostName <hostname>

...

SSH

FIXME
There are so many tutorials available about how to configure and/or secure sshd that we do not need to explain these points.

Check fingerprint

Prints fingerprint of the server’s RSA key:

ssh-keygen -l -f /private/etc/ssh_host_rsa_key.pub

FIXME

sshd

FIXME

Client's side

FIXME
Edit /private/etc/sshd_config

Change PasswordAuthentication yes to PasswordAuthentication no
Change RSAAuthentication yes to RSAAuthentication no if key-based authentication is used

more

FIXME

Tunneling

From the man:

 The following example tunnels an IRC session from client machine ``127.0.0.1'' (localhost) to remote server
     ``server.example.com'':

         $ ssh -f -L 1234:localhost:6667 server.example.com sleep 10
         $ irc -c '#users' -p 1234 pinky 127.0.0.1

Perimetric security

Preventing RF eavesdroppers

Faraday cage

Blocks out external static electrical fields and shield the interior from external electromagnetic radiation.
Named after physicist Michael Faraday, who built one in 1836.

You can also encrypt your communication and/or add noise if you cannot managed to block output emits, though according to "Shannon", it's probably not the most efficient way.

Wireless emission

No driver reported to work at this time. See Network page for update.
freeradius and openradius (802.11X could be then tested, though wireless is not mandatory for this kind of service).
Reduce power emit.
Add "many" fakeap clones.
WPA2 minimum.
etc...
http://www.swisswireless.org/wlan_calc_en.html

Bluetooth

No support known on Darwin (need investigation).

Screen disclosure

Away from the screen, no information nor open privileged prompt should remain.
Potential solution(s):
  • removing scrollback buffer (is it possible on Darwin? is there any scrollback first?)
  • Screen blanking
  • Automatic logout (nyi)
  • Screensaver
  • etc..

Disable some kext to avoid potential physical security flaws

Remove Airport support

No driver available at this time or reported to work, although the operation should be similar as below.

You can safely remove it if you don't plan to use wireless network interface:
sudo srm -Rf /System/Library/Extensions/AppleAirPort.kext
sudo touch /System/Library/Extensions

Remove bluetooth support

No driver available at this time or reported to work, although the operation should be similar as below.

Prevent someone to reach your computer bluetooth:
sudo srm -Rf /System/Library/Extensions/IOBluetoothFamily.kext
sudo srm -Rf /System/Library/Extensions/IOBluetoothHIDDriver.kext
sudo touch /System/Library/Extensions

Removing audio support

No driver available at this time or reported to work, although the operation should be similar as below.

Prevent someone to listen your microphone:

sudo srm -Rf /System/Library/Extensions/AppleOnboardAudio.kext
sudo srm -Rf /System/Library/Extensions/AppleUSBAudio.kext
sudo srm -Rf /System/Library/Extensions/AudioDeviceTreeUpdater.kext
sudo srm -Rf /System/Library/Extensions/IOAudioFamily.kext
sudo srm -Rf /System/Library/Extensions/VirtualAudioDriver.kext
sudo touch /System/Library/Extensions

Removing video support

No driver available at this time or reported to work, although the operation should be similar as below.
Prevent someone trying to watch your webcam:
sudo srm -rf /System/Library/Extensions/Apple_iSight.kext
sudo srm -rf /System/Library/Extensions/IOUSBFamily.kext/Contents/PlugIns/AppleUSBVideoSupport.kext
sudo touch /System/Library/Extensions

Removing USB support

Warning: Since we boot on USB we shouldn't remove this one.
You probably can safely remove this one if you boot on firewire, cdrom, in a vm or other medium:

sudo srm -rf /System/Library/Extensions/IOUSBMassStorageClass.kext
sudo touch /System/Library/Extensions

Removing FireWire support

Except if you boot on firewire or simply need it, you could safely remove this one:

sudo srm -rf /System/Library/Extensions/IOFireWireSerialBusProtocolTransport.kext
sudo touch /System/Library/Extensions

Serialization

ioreg

The I/O Kit registry is an abstraction layer of some logical and physical information. We can use it to retrieve some unique identifiers.
Write somewhere (away from your computer) as serials you will find as possible:

ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/IOPlatformSerialNumber/ {print $4}'
Q723******

ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/product-name/ {print $4}'
MacBook2,1

ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/board-id/ {print $4}'
Mac-F420****

ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/IOPlatformUUID/ {print $4}'
00000000-0000-**00-**00-0019E33****

ioreg -c "ATADeviceNub" | awk -F '"' '/device serial/ {print $4}'
K0075******

ioreg -c "AppleAHCIDiskDriver" | awk -F '"' '/Serial Number/ {print $4}'
        K439T7******

ioreg -l | grep -i 'serial number'
    | |   |         |   "Serial Number" = "        K439********"

ioreg -l | grep -i 'serialnumber'
    |   "IOPlatformSerialNumber" = "WQ7********"
    | |           "BatterySerialNumber" = "DP-ASM****-3***-3***"
    | |           "SerialNumber" = 12***

ioreg -l | grep -i 'serial-number'
    |   "serial-number" = <594***0000000000000000000057513************941**00000000000000000000000000000000000000>

ioreg -l | grep -i 'device serial'
    | |   |   |     |   "device serial" = "K0075S*****         "

ioreg -l -w0 -p IODeviceTree | grep device-prop
   | |   "device-properties" = <ef0900000100000002000000280900002700000002010c00d.....

Backup and checksum

Usefull behaviors.

Pseudo backup tools

This list is not exhaustive and this page is not about a complete guide on "how to backup well"; depending your tastes and tool availability, there are several ways to achieve correct backuping and many tools:
  • ditto
  • dump/restore
  • pax
  • rsync
  • scp
  • tar
For more information, take a look at http://developer.apple.com/macosx/backuponmacosx.html.

Checksum

We use internally a checksum list for binary roots and binary drivers intregrity (not for security purpose).
The DarwinBuild project and the MacPorts project also maintain and check integrity of their sources and binaries.
Paranoid: Strong Fingerprints must be trusted and encrypted or stored in an encrypted disk image.

md5

Try to avoid for historic security purposes, collisions are easy to create.

SHA-1

Collisions can be created but it's "ok" for literal integrity purpose (not for fingerprint security purpose).

/usr/bin/openssl sha1 mach_kernel
SHA1(BuildRoot/mach_kernel)= 19cecd3bd87c10bc4e2c167188a299a40c10d199

Paranoid: Best is to use a concatenation of several strong checksums.

SHA-2 family

FIXME

Appendix

The dynamic linker library (dyld)

FIXME
dyld can:
  • Dynamically link new libraries into memory
  • Recover base addresses for existing libraries
Library offsets are not randomized between
  • invocations of the same program
  • invocations of different programs
but seems to not be the same from different leopard install.

FIXME

Disable Spotlight for a volume and erase its current meta data


mdutil -E -i off $PUREDARWIN

Defeat nmap fingerprint

Choose value between available choices:

sysctl -w net.inet.tcp.blackhole=[0 | 1 | 2]
sysctl -w net.inet.udp.blackhole=[0 | 1]

It doesnt seem to have any effect.

Tools and more

bro
prelude
Found in MacPorts
SourceFire/Snort (MP)
chkrootkit (MP)
nmap (MP)
rkhunter (?)
tripwire (MP)
etc..

Initial version on MMVIII VI VIII  2008/06/08
